Modern Defense Technology ›› 2024, Vol. 52 ›› Issue (1): 111-115.DOI: 10.3969/j.issn.1009-086x.2024.01.014

• INTEGRATED LOGISTICS SUPPORT TECHNOLOGY • Previous Articles     Next Articles

Research on the Technology of Multi-functional Naval Missile Carrier

Xiaojun WANG1(), Ping REN1, Shulin CUI2, Lili ZHAO1

  1. 1.Beijing Institute of Mechanical Equipment, Beijing 100854, China
    2.Military Representatives Office of Navy in the Second Research Academy of CASIC, Beijing 100854, China
  • Received:2023-03-14 Revised:2023-04-12 Online:2024-02-28 Published:2024-02-21
  • Contact: Ping REN

多功能海军导弹运输车技术研究

汪晓军1(), 任平1, 崔树林2, 赵丽丽1

  1. 1.北京机械设备研究所,北京 100854
    2.海装驻北京地区第二军事代表室,北京 100854
  • 通讯作者: 任平
  • 作者简介:汪晓军(1975-),男,河南许昌人。研究员,硕士,研究方向为发射系统、智能装备及地面设备技术。E-mail:wxj@126.com

Abstract:

Aiming at the problems of single function, poor versatility, cumbersome loading operation process and long time in the process of missile transfer and loading, a technical scheme of multi-functional missile transport vehicle is proposed.The scheme takes the design concept of generalization and structural function integration, integrating the transport function and auxiliary erection function of the transport vehicle.The horizontal and vertical attitude conversion functions of the missile are integrated under the premise of meeting the road transportation functions of various types of missiles in Haitong.The limitation of the loading method of missile on the ship is broken.The problem of complicated lifting procedure in the process of missile loading on the ship is solved, the function of directly lifting the vertical missile-in-container on the transport vehicle is achieved, and the time of missile-in-container loading ship is shorten. The scheme simplifies the process of shipborne missile transfer and loading, and the efficiency of equipment use is improved.

Key words: missile transport, loading, universal method, erection, attitude conversion, multi-functional integration

摘要:

针对海军舰载导弹转运及装舰过程中,运输车功能单一、通用性差,且装舰操作流程繁琐、时间长的问题,提出一种多功能导弹运输车的技术方案,该方案以通用化和结构功能一体化为设计理念,对运输车的运输功能与辅助起竖功能进行一体化设计,在满足海通各型导弹公路运输功能的前提下,集成导弹水平、垂直姿态转换的功能,突破筒弹在舰面装填方式的限制,解决筒弹装舰过程中吊装流程繁琐的问题,实现在运输车上直接起竖筒弹的功能,缩短筒弹装舰时间。该方案使得舰载导弹转运、装舰的流程得以简化,提升了装备的使用效能。

关键词: 导弹运输, 装填, 通用, 起竖, 姿态转换, 多功能集成
